Full Automatic Fresh Fruit Juice Drink Production Processing Line Juice Hot Filling Machine

Product Details:

Contact Now

Detailed Product Description

应用:	饮料	包装类型:	瓶, 机筒
包装材料:	塑料	自动化程度:	全自动
动力类型:	Electric	电压:	220V, 380V, 400V, 415V, 460V
原产地:	Jiangsu, China	品牌:	Dongshi
尺寸(长×宽×高):	2400x1650x2500mm	保修期:	1年
核心卖点:	高生产率	填充物料:	Juice
灌装精度:	99%	机械测试报告:	可提供
视频出厂验货:	可提供	核心组件:	泵, PLC
加注喷嘴:	2	售后服务体系:	在线支持, 视频技术支持, 免费备件, 现场安装、调试及培训
重量 (KG):	250	填充量:	500ml
Product Name:	Liquid Filling Machine	Filling Material:	Drinking Water,juice
Bottle Type:	3-5 Gallon	Keywords:	Juice Fillng Machine
Name:	Automatic Juice Filling Machine	Usage:	Liquid Packaging
Processing Types:	Automatic Bottle Filling Sealing Machine	Capacity:	3000BPH
Material:	304

Product Description

Factory Layout-Juice Filling Line

Automatic capping machine

After the bottle enters the extraction cover area, the detection element completes the detection of the barrel position, and the cylinder block of the bottle block position the barrel. Pull cover cylinder action, pull cover head overall down, grab cover cylinder action, grab cover back pull cover cylinder action, pull cover head overall up, complete pull cover.

Brush washout

The empty barrel is entered into the external washing machine by the device of feeding the bottle and pulling the wheel. The center main brush is used to wash the mouth and body of the barrel. The four bottom brushes are self-transmitted simultaneously with the central brush, which can fully remove the bottom dirt of the barrel during the washing process, and assist other brushes to keep the barrel balance. With detergent auxiliary spray, there is no cleaning dead angle and blind area, at the outlet of the barrel, clean water spray system will wash the washing detergent clean.

Automatic bottle

The automatic bottle feeding part is composed of adjustable height equal pitch bottle conveying chain, bottle beating mechanism, bottle feeding mechanism, etc. The equal pitch transport chain ensures the consistency of the distance, the height of the transport chain is adjustable, and the drop of the five gallon bottle is moderate.

Flush and filling

Barreled line is the core equipment for 5 gallon barreled drinking water production line. Is pure water, pure water production ideal equipment. Made of high quality stainless steel, corrosion resistant, easy to clean

Light inspection

The lamp inspection box adopts stainless steel protective outer cover, the light illumination is comfortable and suitable, not only conforms to the national hygiene standard, but also can clearly check the impurities, defects and particles inside and outside the barrel.

Product Paramenters

Model	XWD40-40-10R	XWD50-50-12R	XWD60-60-15R
capatity(b/h)	15000	18000	21000
Moto power(kw)	6.5	8	12
Filling heads	40	50	60

Our Service

1.Provide a full set of production process parameters. 2.All equipment and required water, electricity and gas shall be arranged according to the requirements of the production line. Driving and raw materials, the supplier sent commissioning process personnel to the factory for equipment installation and commissioning. The buyer arranges 2-3 employees to cooperate with the master to install and debug. 3. Provide spare parts for one year at random. 4.The full set of equipment provides one year warranty under normal production conditions. 5.Provide technical support and new process research results at any time.

Packing&Shipping

Customer Photos

Company Profile

Zhangjiagang Dongshi Machinery Co., Ltd. is the production of small and medium-sized beer, drinks, various specifications of liquid filling machinery equipment blowing machine equipment professional units. Our unit insists on market-oriented, science and technology as the leading, quality as the main line, service as the guarantee, establish a sound quality assurance system, and equipped with perfect testing and inspection facilities, we have a quality of technology development and production and manufacturing staff, with rich design and manufacturing experience. We offer all kinds of carbonated drinks, pure water, mineral water, juice, soy milk, alcohol and other edible liquid bottles, cans, cups, barreled, hot filling to our customers at home and abroad Set of equipment and drinking water, mineral water, pure water and other water treatment equipment. RCGF series, CGF series, DCGF series bottled and QGF bottled beverage production bottled beverage production line, the QHS series beverage mixer, all digested and absorbed Germany, Italy, Japan's advanced technology manufacturing, with the 1990s international advanced level. At the same time, our unit can provide customers with process consulting, plant graphic design, installation and commissioning, technical training and other supporting services. At present, the company's products sell well in 29 provinces, cities, autonomous regions, and exported to Southeast Asia, Russia, West Asia, Africa and more than 20 countries and regions.
