Name: Water Treatment Machinery RO Water Treatment System Machinery for Effective Water Purification
Brand: Zhangjiagang Dongshi Machinery Co., Ltd.
Availability: InStock

Home Products water treatment

Water Treatment Machinery RO Water Treatment System Machinery for Effective Water Purification

Product Details:

Contact Now

Detailed Product Description

视频出厂验货:	可提供	机械测试报告:	可提供
核心组件:	泵, 电机	原产地:	Jiangsu, China
品牌:	Dongshi	保修期:	1年
生产率:	2000升/小时	重量 (KG):	500
加工工艺:	反渗透系统	功率(马力):	2KW
电压:	220V, 380V	Product Name:	Water Treatment System
Material:	SUS304/316	Application:	Water Juice
Keywords:	RO Water Filtration

Product Description

Water Treatment is for producing drinking water, foods factory, beverage factory, fruit& vegetable factory etc. The
machine is integrated into a group, the assembly and transportation are rather convenient.
(1) Raw water tank + Raw water pump
(2) Silica sand filter + Active carbon filter + Sodium ion exchanger + Precision filter + Security filter
(3) Reverse Osmosis (one level)
(4) UV sterilizer
(5) Finished water tank + Pure water pump

Original water pump

Runtime overcomes preprocessor resistance while providing sufficient water flow to backwash the preprocessor. Equipped with overload and thermal protection; the low water level valve through the original tank can prevent it from idling.

Quartz sand filter

Quartz sand filter is through the filter bed, the removal of suspended matter condensation of the sheet and precipitation method can not remove the adhesive colloid. It is mainly used for the pretreatment of softening, desalting and pure water system, and also for the coarse filtration of industrial water supply with low requirements. According to the situation of using filter media, mechanical filter can be divided into single layer filter, double layer filter and multi layer filter.

The equipment can remove heterochromatic, odorous and heavy metals such as mercury, lead, cadmium, zinc, iron, manganese and chromium in clear water. It can also remove arsenic, hydride, sulphide, residual chlorine and other radioactive substances such as strontium, radium, etc. is the ideal water supply equipment for domestic drinking water, food, beverage, pharmaceutical, chemical and other industrial purification water.

Sodium ion exchanger anion and cation exchanger is the main equipment for initial desalination of water or preparation of high purity water. When the salt content of raw water is below 500 mg/L, the salt content of effluent can be reduced to about 5~10 m/L after treatment by anion and cation exchanger, which can be directly supplied to high pressure boiler or industrial water such as electronics, chemical industry, medicine, atomic energy and so on

reverse osmosis (RO) technology is the key to reverse osmosis membrane. Reverse osmosis membrane is a chemical synthesis polymer membrane, in the synthesis process through the action of molecules between the reverse osmosis membrane has a lot of pores. The reverse osmosis membrane removes impurities thoroughly through particle size selection and rejection of charged particles

Ozone is an isomer of oxygen with a density of 1.658 heavier than air. It is a blue gas and one of the strongest oxidants known. It can kill cells, spores, viruses and dust. a high-dose broad-spectrum fungicide. In addition, it also has the function of decomposing organic matter, removing stench, bleaching and so on. The stability of ozone factor is poor, which is quickly decomposed into oxygen and single oxygen atom. There is no toxic residue, so it is also called no secondary pollution high efficiency disinfection sterilizer

Technical parameters

Source pump	Quartz Sand Filter	carbon filter	sodium-ion exchanger	Hollow ultrafiltration
Flow :6 T/h	Material :304 stainless steel	Capacity :6 T/h	Medium: High quality 001×7 resin	Capacity :6m3/hr
Head :30 m	Capacity :6T/h	Material :304 stainless steel.	Amount of resin: L 430	Filter accuracy :0.02 um
Size :600×180×270 mm		Weight :500 kg	Material :304 stainless steel. (Lining glue)

Related Products

Packing&Shipping

Customer Photos

Company Profile

Zhangjiagang Dongshi Machinery Co., Ltd. is the production of small and medium-sized beer, drinks, various specifications of liquid filling machinery equipment blowing machine equipment professional units. Our unit insists on market-oriented, science and technology as the leading, quality as the main line, service as the guarantee, establish a sound quality assurance system, and equipped with perfect testing and inspection facilities, we have a quality of technology development and production and manufacturing staff, with rich design and manufacturing experience. We offer all kinds of carbonated drinks, pure water, mineral water, juice, soy milk, alcohol and other edible liquid bottles, cans, cups, barreled, hot filling to our customers at home and abroad Set of equipment and drinking water, mineral water, pure water and other water treatment equipment. RCGF series, CGF series, DCGF series bottled and QGF bottled beverage production bottled beverage production line, the QHS series beverage mixer, all digested and absorbed Germany, Italy, Japan's advanced technology manufacturing, with the 1990s international advanced level. At the same time, our unit can provide customers with process consulting, plant graphic design, installation and commissioning, technical training and other supporting services. At present, the company's products sell well in 29 provinces, cities, autonomous regions, and exported to Southeast Asia, Russia, West Asia, Africa and more than 20 countries and regions.

Above Price Is Not Accurate,Only For Your Reference. If You Need Latest Quotation,Please Contact Us! Send your Inquiry Details in the Below , Click "Send" Now
